Single Phase 110V

Type		Output (W)	Staring Torque (g-cm)	Rated Torque (g-cm)	Rated Current (A)	Electric Capacity (uF)	Appropriate Reducer		Maximum Allowable Loading Capacity (kg-cm)
Cylindrical Shaft	Gear Shaft	Output (W)	Staring Torque (g-cm)	Rated Torque (g-cm)	Rated Current (A)	Electric Capacity (uF)	Appropriate Reducer		Maximum Allowable Loading Capacity (kg-cm)
2IK6RA-A	2IK6RGN-A	6	380	250~330	0.24	2.5	2GN□	2GN□K	25
3IK15RA-A	3IK15RGN-A	15	750	300~800	0.56	4	3GN□	3GN□K	50
4IK25RA-A	4IK25RGN-A	25	1300	450~1400	1.0	6	4GN□	4GN□K	80
5IK40RA-A	5IK40RGN-A	40	2300	600~2400	1.5	12	5GN□	5GN□K	100
5IK60RA-AF	5IK60RGN-AF	60	4200	1200~3700	2.4	14	5GN□	5GN□K	100
5IK60RA-AF	5IK60RGX-AF	60	4200	1200~3700	2.4	14	-	5GX□K	250
5IK90RA-AF	5IK90RGX-AF	90	5500	2500~5500	2.9	25	-	5GX□K	250
5IK120RA-AFF	5IK120RGX-AFF	120	6500	2500~6000	4	30	-	5GX□K	250

Note : Frequency (HZ) 50/60. Polarization Number : (P) 4. Revolution (r.p.m.) 90/1750.
Rated Time : Continue.

Single Phase 220V

Type		Output (W)	Staring Torque (g-cm)	Rated Torque (g-cm)	Rated Current (A)	Electric Capacity (uF)	Appropriate Reducer		Maximum Allowable Loading Capacity (kg-cm)
Cylindrical Shaft	Gear Shaft	Output (W)	Staring Torque (g-cm)	Rated Torque (g-cm)	Rated Current (A)	Electric Capacity (uF)	Appropriate Reducer		Maximum Allowable Loading Capacity (kg-cm)
2IK6RA-C	2IK6RGN-C	6	380	250~330	0.12	0.8	2GN□	2GN□K	25
3IK15RA-C	3IK15RGN-C	15	750	300~800	0.28	1.0	3GN□	3GN□K	50
4IK25RA-C	4IK25RGN-C	25	1300	450~1400	0.5	1.5	4GN□	4GN□K	80
5IK40RA-C	5IK40RGN-C	40	2300	600~2400	0.8	2.5	5GN□	5GN□K	100
5IK60RA-CF	5IK60RGN-CF	60	4200	1200~3700	1.2	3	5GN□	5GN□K	100
5IK60RA-CF	5IK60RGX-CF	60	4200	1200~3700	1.2	3	-	5GX□K	250
5IK90RA-CF	5IK90RGX-CF	90	5500	2500~5500	1.5	5	-	5GX□K	250
5IK120RA-CFF	5IK120RGX-CFF	120	6500	2500~6000	2	6	-	5GX□K	250

Note : Frequency (HZ) 50/60. Polarization Number : (P) 4. Revolution (r.p.m.) 90/1750.
Rated Time : Continue.
