Single Phase 110V

Type		Output (W)	Staring Torque (g-cm)	Rated Torque (g-cm)	Rated Current (A)	Electric Capacity (uF)	Appropriate Reducer		Maximum Allowable Loading Capacity (kg-cm)
Cylindrical Shaft	Gear Shaft	Output (W)	Staring Torque (g-cm)	Rated Torque (g-cm)	Rated Current (A)	Electric Capacity (uF)	Appropriate Reducer		Maximum Allowable Loading Capacity (kg-cm)
2RK6RA-A	2RK6RGN-A	6	390	310~320	0.23	3	2GN□	2GN□K	25
3RK15RA-A	3RK15RGN-A	15	820	470~1000	0.38	5	3GN□	3GN□K	50
4RK25RA-A	4RK25RGN-A	25	2100	900~1600	0.58	8	4GN□	4GN□K	80
5RK40RA-A	5RK40RGN-A	40	2400	1000~2500	0.9	14	5GN□	5GN□K	100
5RK60RA-AF	5RK60RGN-AF	60	4700	1200~3800	1.5	16	5GN□	5GN□K	100
5RK60RA-AF	5RK60RGX-AF	60	4700	1200~3800	1.5	16	-	5GX□K	250
5RK90RA-AF	5RK90RGX-AF	90	5800	2500~5500	2.0	25	-	5GX□K	250

Note : Frequency (HZ) 50/60. Polarization Number : (P) 4. Revolution (r.p.m.) 90/1750.
Rated Time : Continue.

Single Phase 220V

Type		Output (W)	Staring Torque (g-cm)	Rated Torque (g-cm)	Rated Current (A)	Electric Capacity (uF)	Appropriate Reducer		Maximum Allowable Loading Capacity (kg-cm)
Cylindrical Shaft	Gear Shaft	Output (W)	Staring Torque (g-cm)	Rated Torque (g-cm)	Rated Current (A)	Electric Capacity (uF)	Appropriate Reducer		Maximum Allowable Loading Capacity (kg-cm)
2RK6RA-C	2RK6RGN-C	6	390	310~320	0.12	0.8	2GN□	2GN□K	25
3RK15RA-C	3RK15RGN-C	15	820	470~1000	0.19	1.2	3GN□	3GN□K	50
4RK25RA-C	4RK25RGN-C	25	2100	900~1600	0.29	2	4GN□	4GN□K	80
5RK40RA-C	5RK40RGN-C	40	2400	1000~2500	0.45	3	5GN□	5GN□K	100
5RK60RA-CF	5RK60RGN-CF	60	4700	1200~3800	0.8	3.5	5GN□	5GN□K	100
5RK60RA-CF	5RK60RGX-CF	60	4700	1200~3800	0.8	3.5	-	5GX□K	250
5RK90RA-CF	5RK90RGX-CF	90	5800	2500~5500	1.0	5	-	5GX□K	250

Note : Frequency (HZ) 50/60. Polarization Number : (P) 4. Revolution (r.p.m.) 90/1750.
Rated Time : 30 minutes.
